1) Press “ ” or “ ”to move cursr to choose the mill type.
2) Press “ ” to enter the scan mill set, it includes: Scan type, Width,
Height, Diameter, Depth, Z Step, T Ratio.
3) Prss “ ” and “ ”to move cursor on the option which need modify,
press “ ” to choose mill type(AC or C), also press this button to
modify the parameters. Press “ ” after modified all the parameters to
save them.
7. Calculate work time
Calculate the processing time according to the system processing speed. After
pre-read processing file, the system will display total processing time. Different
processing speed will correspond to different processing time.
8. Find break no
Look for position line number. If accidentally cutter break and user hasn’t saved
the break point, reboot system and replace the cutter. After that, user can manually
move X, Y axis to the nearest point where the cutter was broken (recommend to move
a little further), press “ ” enter into “Find break no.”, afterwards choose the
previous processing file, the system will prompt “searching current position”. System
Scan mill set
Scan Type AC
Width 100.000
Height 100.000
Diameter 10.000
Depth 0.100
Z Step 0.100
T Ratio 0.800
