PM Table
D017/D018/D019/D020 2-2 SM
EM 120K 240K 360K NOTE
Unit
ID Sensor C C C
Perform the ID sensor initial
setting (SP2-935) after
cleaning (blower brush)
EM 60K 120K 180K NOTE
PCU
Drum R R R
Charge Roller R R R
Cleaning Roller R R R
Cleaning Blade R R R
Pick-off Pawls R R R
Developer R R R
Do SP2801. This initializes the
developer and resets the TD
and ID sensor outputs to their
defaults. It also resets the
PCU counter.
EM 120K 240K 360K NOTE
PAPER FEED
Registration Rollers C C C C Clean with water
Paper Feed Roller C R R R Clean with water
Friction Pad C R R R Dry cloth
Paper Feed Guides C C C C Clean with alcohol.
Relay Rollers C C C C Clean with water.
Bottom Plate Pad C C C C Clean with water.
Registration Roller
Mylar
C C C C Clean with water.
To Next Page
