Using the Debug Log
D017/D018/D019/D020 5-220 SM
Example 2: To Specify an SC Code
Touch “3 Any SC Error”, enter the 3-digit SC code number with the operation panel
number keys, then press . This example shows an entry for SC670.
For details about SC code numbers, please refer to the SC tables in Section 4.
Troubleshooting.
6. Next, select the one or more memory modules for reading and recording debug
information. Touch “5859”.
7. Under “5859” press the appropriate key item for the module that you want to record.
8. Enter the appropriate 4-digit number, then press .
Refer to the two tables below for the 4-digit numbers to enter for each key.
The example below shows “Key 1” with “2222” entered.
The following keys can be set with the corresponding numbers. (The initials in parentheses
indicate the names of the modules.)
4-Digit Entries for Keys 1 to 10
Key No. Copy Printer Scanner Web
1 2222 (SCS)
2 2223 (SRM)
3 256 (IMH)
4 1000 (ECS)
5 1025 (MCS)
