Using the Debug Log
SM 5-221 D017/D018/D019/D020
Service
Tables
Key No. Copy Printer Scanner Web
6 4848(COPY) 4400 (GPS) 5375 (Scan) 5682 (NFA)
7 2224 (BCU) 4500 (PDL) 5682 (NFA) 6600 (WebDB)
8
4600
(GPS-PM)
3000 (NCS) 3300 (PTS)
9 2000 (NCS) 2000 (NCS) 6666 (WebSys)
10 2224 (BCU) 2000 (NCS)
The default settings for Keys 1 to 10 are all zero (“0”).
Key to Acronyms
Acronym Meaning Acronym Meaning
ECS Engine Control Service NFA Net File Application
GPS GW Print Service PDL Printer Design Language
GSP-PM
GW Print Service – Print
Module
PTS Print Server
IMH Image Memory Handler SCS System Control Service
MCS Memory Control Service SRM
System Resource
Management
NCS Network Control Service WebDB
Web Document Box
(Document Server)
The machine is now set to record the debugging information automatically on the HDD (the
target selected with SP5-857-002) for the events that you selected SP5-858 and the
memory modules selected with SP5-859.
Please keep the following important points in mind when you are doing this setting:
The number entries for Keys 1 to 5 are the same for the Copy, Printer, Scanner, and
Web memory modules.
