Appendix
96
9
C Lift the printer by using the inset grips on both sides of the printer, and
then move it horizontally to the place where you want to use it.
D If you have removed tray 2, reinstall it.
Note
Be sure to hold the printer level while carrying it. To prevent toner from
spilling, move the printer carefully.
Moving over a Long Distance
If you intend to move the printer over a long distance, you must pack it well.
Empty all the paper trays, but do not remove the print cartridge. Take care not
to tip or tilt the printer during transit.
Important
Do not remove the print cartridge when moving the printer.
A Be sure to check the following points:
The power switch is turned off.
The power cord is unplugged from the wall outlet.
All other cables are unplugged from the printer.
All paper trays are empty.
B If tray 2 is installed, remove it.
Note
Toner might spill inside the printer if the printer is not kept level during
transit.
For more information about moving the printer, contact your sales or serv-
ice representative.
BXG010
