Ricoh Aficio SP 3410DN Hardware Guide

Paper and Other Media
50
4
Loading Paper in Tray 2
The following example explains the loading procedure for tray 2.
A Pull tray 2, and then pull it out with both hands.
Place the tray on a flat surface.
B Pinch the clips on the side paper guide, and then slide it to match the paper
size.
C Pinch the clip on the end paper guide and slide it inward to match the paper
size.
BXG048
BXG032
BXG105

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
