Ricoh Aficio SP 3410DN Hardware Guide

Loading Paper
53
4
Loading Paper in the Bypass Tray
Important
❒ Set the size and direction of the loaded paper using Smart Organizing Moni-
tor or the printer driver. Make sure the settings do not conflict. Otherwise, the
paper may jam or the print quality may be affected.
❒ Load paper with the print side up, and in the short-edge feed direction.
❒ If paper is curled, straighten it before loading, by bending it the paper in the
opposite direction to the curl, for example.
❒ Do not load paper while the printer is printing.
❒ You cannot load paper when the printer is in Energy Saver mode. To disable
Energy Saver mode, click the {Stop/Start} key on the control panel.
A Open the bypass tray.
If you load A4 (297 mm) or larger size paper, pull out the bypass tray extension.
BXG050
BXG051

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
