Ricoh Aficio SP 3410DN Hardware Guide

Removing Misfed Paper
90
8
G Using both hands, carefully push up the front cover until it closes.
Note
❒ When closing the front cover, push the upper area of the cover firmly.
After closing the cover, check that the error is cleared.
Removing Jammed Paper from the Exit Area/Duplex Unit
Use the following procedure to remove paper that has become jammed in the
exit area or inside the duplex unit.
R
CAUTION:
A Open the rear cover.
• The inside of this machine becomes very hot. Do not touch parts labelled
“v” (indicating a hot surface).
BXG061
BXG069

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
