Ricoh Aficio SP 3410DN Hardware Guide

Removing Misfed Paper
88
8
Removing Jammed Paper from the Bypass Tray
Use the following procedure to remove paper that has become jammed after being
fed in from the bypass tray.
R
CAUTION:
A If paper is jammed in the bypass tray input area, remove the jammed paper
carefully.
B Close the bypass tray.
C Push the side button to open the front cover, and then carefully lower it.
• The inside of this machine becomes very hot. Do not touch parts labelled
“v” (indicating a hot surface).
BXG068
BXG057

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
