Ricoh Aficio SP 3410DN Hardware Guide

Installing the Printer
21
2
L Pull out and raise the stop fence.
Turning the Power On
Follow the procedure below to turn the power on.
R
WARNING:
Important
❒ Make sure the power cable is plugged securely into the wall outlet.
❒ Turn the power switch off when plugging and unplugging the power plug.
❒ Do not turn off the power switch until initializing is completed. Doing so
results in malfunction.
A Plug in the power cable.
• Plug and unplug the power cable with dry hands, or an electric shock
could occur.
BXG019
BXG020

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
