Ricoh Aficio SP 3410DN Hardware Guide

Replacing Consumables
60
5
❖ When to replace the print cartridge
If the Alert indicator or Replace Print Cartridge indicator on the control panel
light up, or the following message appears on the Smart Organizing Monitor
dialog box, replace the print cartridge.
“
No Toner.”
“
No Toner or Waste Toner full.”
Important
❒ Do not allow paper clips, staples, or other small metallic objects to fall inside
the printer.
❒ Do not expose the print cartridge without its cover to direct sunlight for a
long time.
❒ Do not touch the print cartridge's photo conductor unit.
❒ If toner runs out, you cannot print until the print cartridge is replaced.
A If paper is loaded in the bypass tray, remove the paper and close the bypass
tray.
B Push the side button to open the front cover, and then carefully lower it.
BSP024S
BXG057

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
