Ricoh Aficio SP C320DN

4. Pinch the extender in the "PUSH" direction, and then pull out the extender until it stops (you
will hear a click).
1
1
2
CBK103
After extension, make sure the arrows on the extender and tray are aligned.
CBK104
5. Pinch the clip on the side paper guide, and then slide it to match the legal paper size.
CBK105
6. Loading Paper
126
6
