Ricoh Aficio SP C320DN

CBK161
7. Hold the center of the new waste toner bottle, and then carefully insert it halfway into the
printer body.
Leave the cap open.
CBK150
To prevent the waste toner bottle touching the intermediate transfer unit, do not lift the bottle while
inserting it.
CBK151
8. Push in the waste toner bottle until it clicks into place.
Push the green part all the way in.
7. Maintaining the Printer
158
7
