Ricoh Aficio SP C320DN User Manual

4. Hold the center of the waste toner bottle, and then carefully pull it out horizontally.
CBK133
5. Pull the waste toner bottle halfway out, grab the bottle, and then pull it straight out.
CBK134
CBK135
To prevent the waste toner bottle touching the intermediate transfer unit, do not lift the bottle while
pulling it out.
Replacing the Intermediate Transfer Unit
163
7

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
