Ricoh Aficio SP C320DN

9. Open the box containing the new intermediate transfer unit and remove the top cover.
CBK143
10. Remove the covering sheet. Then, while taking care not to touch the belt area, lift the new
intermediate transfer unit from its box using the grips on both sides.
CBK144
11. While holding the frame of the intermediate transfer unit steady with one hand, use your
other hand to pull the side tab outwards and then upwards to remove the attachment.
CBK145
7. Maintaining the Printer
166
7
