Ricoh Aficio SP C320DN

15. Hold the center of the waste toner bottle, and then carefully insert into the printer body.
CBK150
To prevent the waste toner bottle touching the intermediate transfer unit, do not lift the bottle while
inserting it.
CBK151
16. Push in the waste toner bottle until it clicks into place.
Push the green part all the way in.
CBK152
Replacing the Intermediate Transfer Unit
169
7
