11. Enter the value (mm), and then press the [OK] key.
Increase the value to shift the print area in the direction indicated by the " " symbol in the diagram
below. Decrease the value to shift the print area in the direction indicated by the " " symbol.
1
2
CBK242
: Print Area
: Paper Feed Direction
Pressing the [ ] or [ ] key decreases or increases the value in steps of 1.0 mm.
12. Press the [OK] key to return to the [Registration] menu.
13. Print the test sheet to confirm the adjustment result.
14. Press the [Menu] key to return to the initial screen.
Adjusting Printing Position
199
8

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
