4. Remove the one screw, and then carefully remove the cover of the SD card slot.
2
CBK084
1
5. Carefully push in the SD card (notched corner upward and leading), until it clicks into place.
CBK085
Insert the SD card in the appropriate slot as follows:
• Upper slot: Camera direct print card, Data overwrite security unit, NetWare card
• Lower slot: HDD encryption unit, VM card
6. Reattach the cover over the SD card. Fasten the one screw to secure the cover.
2
CBK086
1
3. Installing Options
66
3

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
