Image Adjustment
C279 4-4 SM
6. Repeat the procedure to make sure that the ratio is correct.
4.3.2 SP6-100 TO 107: PAPER REGISTRATION
1. Input SP8-10 (Test patterns) and enter “6”, then press the Start key.
2. Exit the SP mode, then print 10 copies at 90 rpm (speed 3). Use the 10th print for the
adjustment.
3. The space between the leading edge and the next line should be 8 mm, as shown above.
4. If it is not, access SP6-100 to 107, input the difference and press the Enter key.
Example: If the value is 7 mm, 7 - 8 = -1.0
5. Repeat the procedure to make sure that the gap is correct.
4.3.3 SP6-05, 6-06: SCANNING SPEED – PLATEN, ADF
1. Make copies of the test pattern printed during the previous adjustments ( p.4-3 "Image
Adjustment"), in platen mode at 90 rpm (speed 3). Use the 10th print for the adjustment.
2. The length of the 8 squares in the feed direction should be 130 mm.
3. If it is not, calculate the reproduction ratio using the following formula.
{(130 - Value) / 130} x 100 = ± X.X % (Round off to one decimal place)
Example: If the value is 133, {(130 - 133) / 130} x 100 = - 2.3 %
4. Access SP6-05, input the calculated ratio, and press the Enter key.
5. Check again to make sure that the ratio is correct.
6. Make copies of the test pattern in ADF mode and repeat the process using SP6-06.
4.3.4 SP6-03, 6-04: SCANNING START POSITION – PLATEN, ADF
1. Make copies of the test pattern printed during the previous adjustments ( p.4-3 "Image
Adjustment"), in platen mode at 90 rpm (speed 3). Use the 10th print for the adjustment.
2. The space between the leading edge and the next line should be 8 mm.
3. If it is not, access SP6-03, input the gap value and press the Enter key.
Example: If the value is 7 mm, 7 - 8 = -1.0
4. Repeat the procedure to make sure that the gap is correct.
5. Make copies of the test pattern in ADF mode and repeat the process using SP6-04.
