OPU

OPU (Printer Models)

1. Operation panel (page 107 "Operation Panel")

2. Remove the key and display assembly [A] from the operation panel. ( × 2, hooks, ×

1, × 1)

3. OPU [B] ( × 3)

OPU (MF Models)

1. Operation panel (page 107 "Operation Panel")

4. Replacement and Adjustment

110
