5. ADF motor assembly [C] ( × 2, ground screw× 1, × 1, ground plate, discharge

brush)

6. ADF motor [D] ( × 2)

ADF Top Cover

1. ADF drive unit (page 47 "ADF Motor")

4. Replacement and Adjustment
