Exterior Covers

• Turn off the main power switch and unplug the printer before you do the procedures in this section.

Rear Cover

Rear Cover (Printer Models)

1. Rear tray cover [A]

2. Interface cover [B] (hook × 1)

4. Replacement and Adjustment
