Paper Exit Sensor

1. Rear cover (page 32 "Rear Cover")

2. Operation panel (page 107 "Operation Panel")

3. Right cover (page 34 "Right Cover")

4. Fusing stripper pawl solenoid assembly [A] ( × 4)

• The upper right screw in the above photo is different from other 3 screws.
