4. Fusing fan motor [B] (2hooks, × 1)
• Install the fusing fan motor with its decal facing the outside of the machine.
Fusing Stripper Pawl Solenoid
1. Open the front cover.
2. Open the top cover.
3. Rear cover (page 32 "Rear Cover")
4. Operation panel (page 107 "Operation Panel")
5. Right cover (page 34 "Right Cover")
4. Replacement and Adjustment
