Ricoh PE-P4 - Wi-Fi Board

2. Remove the rear cover [A] from the operation panel. ( × 5)
3. OPU [B] ( × 10, × 2, 2 hooks)
Wi-Fi Board
1. Rear cover (page 32 "Rear Cover")
2. Operation panel (page 107 "Operation Panel")
3. Right cover (page 34 "Right Cover")
4. Remove the Wi-Fi Board [A] with the bracket. ( × 1, ×1)
Electrical Components
111
