2. ADF feed roller [A]

ADF Separation Pad

1. Open the ADF top cover.

2. ADF separation pad [A] (2 hooks, spring × 1)

ADF Front Cover

1. ADF unit (page 42 "ADF Unit")

2. Original tray (page 43 "Original Tray")

3. Turn the ADF unit over.

ADF (only for MF Models)
