Using an Ethernet Cable
1. Turn on your computer.
2. Insert the provided CD-ROM into the CD-ROM drive of the computer.
If your computer does not have a CD-ROM drive, download a setup file from our website.
3. Double-click the CD-ROM drive icon.
4. Double-click the [macOS] folder.
5. Double-click the folder of driver you want to install.
6. Follow the instructions in the setup wizard.
7. Click [Close] in the [Summary] dialog box.
8. Start System Preferences.
9. Click [Printers & Scanners].
10. Click the [+] button.
If [Add Printer or Scanner...] appears, click it.
11. Click [Default].
12. Select the printer that has "Bonjour" indicated in the [Kind] column.
If the printer name is not displayed, select the icon that corresponds to your network environment
(TCP/IP, etc.).
13. Select the printer you are using from the [Use:] pop-up menu.
14. Click [Add].
15. Click [Duplexer] on the [Setting up] screen, and then click [OK].
16. Quit System Preferences.
17. Press the [Menu] key.
18. Press the [
] or [ ] key to select [Host Interface], and then press the [OK] key.
19. Press the [ ] or [ ] key to select [Network Setting], and then press the [OK] key.
20. Press the [ ] or [ ] key to select [DHCP], and then press the [OK] key.
21. Press the [ ] or [ ] key to select [Active] to automatically obtain the IP address or
[Inactive] to specify the IP address manually.
If you have selected [Active], proceed to Step 28.
22. Press the [ ] or [ ] key to select [IP Address], and then press the [OK] key.
23. Enter the machine's IPv4 address, and then press the [OK] key.
24. Press the [ ] or [ ] key to select [Subnet Mask], and then press the [OK] key.
25. Enter the subnet mask, and then press the [OK] key.
26. Press the [ ] or [ ] key to select [Gateway Address], and then press the [OK] key.
8. Configuring Network Settings Using OS X
182
