2. Remove the adhesive tape from the optional paper feed unit.
3. Lift the machine using the inset grips on both sides. Lifting the machine requires two
people.
4. There are three upright pins on the optional paper feed unit. Align the holes of the
machine with the pins, and then lower the machine slowly.
5. Plug the machine's cord back into the wall outlet, and then turn on the power.
• After installing the optional paper feed unit, select Tray 2 in the printer driver. For details, see the
printer driver Help.
• If the new device is listed in the column of configuration options, it has been properly installed.
1. Guide to the Machine
20
