1.Detailed Descriptions
23
No.
Part
3
Booklet Tray Full Sensor 1
4
Booklet Exit Sensor
5
Fold Plate Cam HP Sensor
6
Fold Transport Motor
7
Press Fold Motor
Punch Unit (Option)
No.
Part
1
Punch Unit Movement Motor
2
Punch Unit HP Sensor
3
Punch Registration HP Sensor
4
Punch Registration Motor
5
Punch Registration Sensor
6
Punchout Hopper Full Sensor
7
Punch HP Sensor
8
Punch Drive Motor
9
Punch Motor Rotation Sensor
10
Punch Unit Controller Board
