Riele 4040+ - Calculation Procedure 13 (TRANSMISSION)

4040+e_22.docx / 06.10.17
ROBERT RIELE GmbH & Co KG Page 38 6 - CALCULATION PROCEDURES
6.4.13 Calculation procedure 13 (TRANSMISSION)
Calculation procedure ..................................................... CP 13
Characteristic ................................................................. T in %
PHOTOMETER 4040+ # 1001
V2.2a dd/mm/yy D
LAB.: RIELE BERLIN
USER 1: M.MUSTERMANN
DATE: 07/17/17
TIME: 08:44:12
METHOD 13: TRANSM.
PROGRAM: 13
FACTOR: 1.0
WAVELENGTH: 546nm
TEMPERATURE: 37C
DELAY: 2s
UNIT: %
MEASURE 100%
NO. ABS. RESULT
1 0.329 46.9
2 1.004 9.9
3 2.020 1.0
Start method selection in the main menu.
See chapter:
4.1 - Measurement with programmed methods
4.2 - Measurement with basic methods
In the case of activated printer the print-out of the method data
follows.
The measuring window is shown.
Method procedure:
Insert / measure zero solution
Insert / measure sample
Insert / measure sample
Insert / measure sample
