Riele 4040+ - Settings Printout

4040+e_22.docx / 06.10.17
ROBERT RIELE GmbH & Co KG Page 56 8- UTILITY PROGRAMS
Not implemented
7.2.5.4 QC EDP
8.2.7 Settings printout
******ACTUAL*SETS*******
DATE: 07/17/17
TIME: 08:44:12
PHOTOMETER 4040+ # 1001
V2.2a dd/mm/yy D
/T1.6
CORE P316 V1.1
PCB LAYOUT a
ADC (DARK ADJ.)
E: 8394148 E: 8392514
FILTER
0:DDD 0% 1:405 12%
2:492 14% 3:546 15%
4:578 16% 5:623 12%
6:999 0% 7:999 0%
8:999 0% 9:999 0%
CH1:340 17%
TEMPERATURE OPTIC
37C 14566
BATTERY: OK
ADC CORRECTION 250
EDP ON (CR-LF)
TOUCH
Mx148 My192 Fx120 Fy100
LANGUAGE
1: ENGLISH
2: GERMAN
KEY SIGNAL ON
M.COUNTER : 351
T.COUNTER : 334:45
S.COUNTER : 402
ADJUST OPTIC POSITION :
P3-1 350 3850 7246
D2/3 3500 D1/2 3396
PROGR. METHODS 0
STORED RESULTS 0
By [START] the program version and the
complete status of the saved settings are
printed out.
The percentage is proportional to the
brightness level.
The percentage value left represents the E
adapter and the right one the D adapter.
S E T T I N G S P R I N T O U T
E X I T S T A R T
