4040+e_22.docx / 06.10.17
ROBERT RIELE GmbH & Co KG Page 58 8- UTILITY PROGRAMS
8.2.11 User name
The names of maximum five users can be
stored permanently.
After calling a method the user is queried.
In case of a stored name an additional line
within the header is sent to the printer or to
the EDP.
Select user by [SELECT]. By [NEW] the
entry of the user name is possible.
Enter the user name via the alphanumeric
keyboard.
Following functions are available:
[a/1] : change to lowercase
[1/A] : change to numeric characters
[A/a] : change to uppercase
[] : delete character
[] : blank
[ESC] : finish input without storage
[ENT] : finish input with storage
The last 10 serious errors are shown or
printed.
The oldest error is shown first. The last error
is always marked with no 1.
By [NEXT] earlier error messages are
shown.
By [PRINT] the complete error list is printed
or output to the serial interface.
For troubleshooting the coded error list can
be consulted (chapter 10.4 - CODED
ERROR MESSAGES).
8.2.13 Key signal ON / OFF
The current status of the key signal is indi-
cated in the first line by OFF or ON.
Change setting by [SELECT].
Save setting permanently by [OK].
Save setting temporarily up to next switch-
off of the device by [EXIT].
The deeper signal tone for error messages
remains active in any case.
K E Y S I G N A L O N
E X I T O K S E L E C T
U S E R N A M E
1:
2:
3:
4:
5:
E X I T N E W S E L E C T
U T I L I T I E S P A G E 3 / 5
N E W U S E R N A M E 1
<
Q W E R T Y U I O P
A S D F G H J K L
E S C Z X C V B N M A / 1 E N T
E R R O R L I S T
N O . 1
D A T E 0 9 / 0 8 / 0 9
E R R O R C O D E 4 6
E X I T P R I N T N E X T
