ROBERT RIELE GmbH & Co KG Page 61 8- UTILITY PROGRAMS
8.2.17 ADC counts (Optic)
Indicated is the current value of the optical
analogue-digital converter. The value is
proportional to the light-current depending
on the boost setting.
(A) value
(B) value = Dark level – (A) value
To a key actuation the system reacts
possibly only after three seconds.
The functions F0 to F9 place the filter wheel
into the positions 0 to 9. The position 0 corre-
sponds to the filter wheel position at the dark
level adjustment.
The function [L] switches the LED off and
on.
[CH] switches between the channels 1-3
and F. The filter positions are disappearing
when channels 1-3 are selected.
P1-3 shows the values of channel 1-3. P0
is the corresponding dark position of the
340 nm channels.
Stop function by [ESC].
8.2.18 Service tools
The service tools are reserved for trained
specialists only and therefore protected by a
password.
Stop function by [ESC].
S E R V I C E T O O L S
P A S S W O R D
1 2 3 4 5 6 7 8
E S C 9 0 . + - E
U T I L I T I E S P A G E 5 / 5
A D C C O U N T S ( O P T I C )
F1 4 0 5 n m 7 6 3 9 4 6 8
7 5 2 8 5 1
L.
F 0 F 1 F 2 F 3 F 4 F 5 F 6 F 7 F 8 F 9
E S C C H S O S 1 S 2 S 3 P 0 P 1 P 2 P 3
