ROBERT RIELE GmbH & Co KG Page 51 8- UTILITY PROGRAMS
8.2.4 Bar Code
The current status of bar code reader is
indicated in the first line by OFF or ON.
Change setting by [SELECT]
Save setting permanently by [OK]
Save setting temporarily up to next switch-
off of the device by [EXIT]
8.2.5 Menu serial COM
A PC or an external printer can be connected to Photometer 4040
+
via the RS 232 serial interface at the back. A
suitable data cable can be supplied (REF 501-002). The connected device must comply with safety standard
EN 60950.
The menu offers following functions:
 Activation and deactivation of EDP
 Activation of remote control
 Activation or deactivation of external
printer with serial interface
 Setting of baud rate
8.2.4.1 EDP ON / OFF
The current status of the EDP (Electronic
Data Processing) interface is indicated in
the first line by OFF or ON.
Change setting by [SELECT]:
 EDP OFF: no output,
 EDP ON (CR-LF): system output
through serial port with CR-LF protocol,
 EDP ON (STX-ETX-BCC): system
output through serial port with STX-
ETX-BCC protocol,
 EDP ON (CR-LF-LOG): after each
measurement a formatted string will be
output through the serial port. (e.g. see
table. 8.2.4.1)
Save setting permanently by [OK]
Save setting temporarily up to next switch-
off of the device by [EXIT]
Table 8.2.5.1
Serial
no.
Method
no.
ID-no.
Sample
no.
Result
Temperature
control
User
Date
Time
2250
20
12345
1
15.5
*
[user name]
09/08/09
09:30:47
U T I L I T I E S S U B M E N U
E D P O N / O F F
R E M O T E M O D E
S E R I A L P R I N T E R
B A U D R A T E E X I T
o 3 7 . 0 ° C i 3 7 . 0 ° C 0 7 / 2 4 / 2 0 1 7 1 0 : 1 4
E D P O F F
E X I T O K S E L E C T
B A R C O D E O F F
E X I T O K S E L E C T
