ROBERT RIELE GmbH & Co KG Page 55 8- UTILITY PROGRAMS
Printout of the monthly memory of a method with serum 2:
** MONTHLY MEMORY **S2 *
DATE: 07/17/17
PHOTOMETER 4040+ # 1001
V2.2a dd/mm/yy D
LAB.: RIELE BERLIN
METHOD 25: GLUCOSE
UNIT: mmol/l
SERUM NO. 5
ID LT-SYS abnormal
LOT G312
COMPANY LABOR+TECH
DATE MAY 11
REQUIRED 14.4
MIN.VALUE 12.1
MAX.VALUE 16.7
QC VALUES n: 20
MEAN m: 13.860
STD.DEVIATION s: 1.012
COEFF.OF VAR CV: 7.298
02/15/10 13.54 -1s 1
02/14/10 14.07 +1s 1
02/13/10 14.69 +1s 1
02/12/10 13.50 -1s 3
02/11/10 14.68 +1s 3
02/10/10 15.33 +2s 1
02/09/10 15.99 +3s 1
02/08/10 15.38 +2s 2
02/07/10 14.61 +1s 1
02/06/10 13.70 -1s 1
02/05/10 12.74 -2s 1
02/04/10 12.13 -2s 1
02/03/10 12.65 -2s 2
02/02/10 13.11 -1s 1
02/01/10 13.88 +1s 3
01/31/10 13.51 -1s 3
01/30/10 13.24 -1s 3
01/29/10 12.50 -2s 1
01/28/10 12.74 -2s 2
01/27/10 13.30 -1s 1
Output dialog
If at least 20 readings are stored in the
monthly memory, these are indicated in the
Levey Jennings plot. In this representation
the deviations can be controlled visually and
thus tendencies or systematic errors be
better recognized.
The keys for the printout are located next to
the curve diagram:
[PRN-N] Start the normal printout of the
data of the current monthly memory. The
single data of the readings are not printed
thereby.
[PRN-E] Start the extended printout of the
data of the current monthly memory. As
shown in the example left, also the single
data of the readings are printed.
[EXIT] Return to QC menu
P R N - N
P R N - E
E X I T
