Riello 20148874 - Technical Description of the Burner; Models Available; Burner Categories - Countries of Destination; Technical Data

20152192
8
GB
Technical description of the burner
4.1 Models available
Tab. A
4.2 Burner categories - Countries of destination
Tab. B
4.3 Technical data
Tab. C
(1)
Reference conditions: Ambient temperature 20°C - Gas temperature 15°C - Barometric pressure 1013 mbar - Altitude 0 m a.s.l.
(2)
Input gas pressure 8)(Fig. 2) with zero pressure in combustion chamber and at maximum burner output.
(3)
Sound pressure measured in manufacturer's combustion lab, with burner operating on test boiler, at maximum, average and minimum modulation
output. The sound power is measured with the “Free Field” method, as per EN 15036, and according to an accurate “Accuracy: Category 3” meas-
urement, as described in EN ISO 3746.
4 Technical description of the burner
Designation Voltage Code
RX 700 S/PV 1N/230/50-60 20148874
RX 850 S/PV 1N/230/50-60 20148875
RX 1000 S/PV 3/400/50-60 20148877
Country of destination Gas category
AT - CH - CZ - ES - FR - GB - GR - HR - IE - IS - IT - LT - PT - RO - SI - SK II2H3P
DE - PL I2E, I3P
NL II2EK3P
HU I2H, I3P
BE I2E(R), I3P
LU I2E
BG - DK - EE - FI - LV - NO - SE I2H
CY - MT I3P
Model RX 700 S/PV RX 850 S/PV RX 1000 S/PV
Type 854T4 926T4 891T4
Power
(1)
Delivery
(1)
min - max
min - max
kW
Mcal/h
140 - 700
120 - 602
170 - 880
147 - 757
180 - 1080
155 - 929
Fuels Natural gas: G20-G25 (methane) - LPG: (G31)
Supply pressure
(2)
- mbar 17 - 65 (G20-G31) 25 - 65 (G25)
Gas valve input diameter 1
1
/
2
”
Operation
– Intermittent (min. 1 stop in 24 hours)
– Modulating
Standard applications Boilers: water, steam, diathermic oil
Ambient temperature °C 0 - 50
Combustion air temperature °C max 60
Burner weight
(without packaging)
kg 48 48 58
Noise level
(3)
dB(A)
Min. Aver-
age
Max. Min. Aver-
age
Max. Min. Aver-
age
Max.
Sound pressure 50.8 62.0 70.3 50.5 59.9 68.5 50.7 65.8 74.9
Sound power 63.6 74.8 83.0 63.3 72.7 81.2 63.4 78.6 87.7
