List of parameters PME71.901...
The following pages have the Menus and the list of parameters
for setting up the LCD AZL 2... Display for the LME 71... control
box with PME 71.901...
The values shown in the “Factory setting” column, in the table be-
low, are only given as a guide (Control box not programmed).
10 List of parameters PME71.901...
Parameter
Modification
Values interval
Resolution
Factory
setting
Password
reading
level to
level
Password
writing level
to level
Nr. Description Min. Max.
000 Internal parameter
41 Password for heating engineering (4 characters) Modification xxxx xxxx --- --- --- OEM
42 Password OEM (5 characters) Modification xxxxx xxxxx --- --- --- OEM
60 Backup/Restore Modification Restore Backup --- --- --- SO
100 General notes
102 Identification date Reading only --- --- --- --- Info ---
103 Identification number Reading only 0 9999 1 0 Info ---
113 Burner identification Modification x xxxxxxxx 1 burnErId Info SO
123 Step control min output. Modification 1% 10% 0.1 2 SO SO
140
Displaying the unit operation mode and display-
ing AZL2...
1 = standard (program phase)
2 = flame 1 (QRA.../ION)
3 = flame 2 (QRB.../QRC...) ® not used
4 = output active (output value)
Modification 1 4 1 4 SO SO
164 Number of resettable start-ups Resettable 0 999999 1 0 Info Info
166 Total number of start-ups Reading only 0 999999 1 0 Info ---
170.00 Switching cycles relay contact K12 Reading only 0 999999 1 0 Info ---
170.01 Switching cycles relay contact K11 Reading only 0 999999 1 0 Info ---
170.02 Switching cycles relay contact K2 Reading only 0 999999 1 0 Info ---
170.03 Switching cycles relay contact K1 Reading only 0 999999 1 0 Info ---
171 Max. relay commutation cycles Reading only 0 999999 1 0 Info ---
200 Burner Control
224 Air pressure switch special time Modification 0s 13.818 s 0.294 s 13.818 s SO OEM
225 Pre-purging time - 2.1 seconds Modification 0s 1237 s 4.851 s 29.106 s SO OEM
226 Spark pre-ignition time Modification 1.029 s 37.485 s 0.147 s 6.174 s SO OEM
230
Interval: End of the safety time - resetting of the
load regulator
Modification 3.234 s 74.97 s 0.294 s 9.408 s SO OEM
234 Post-purging time Modification 0s 1237 s 4.851 s 19.404 s SO OEM
235
Air pressure switch input
0 = inactive
1 = active
Modification 0 1 1 0 SO OEM
240.00
Repetitions meter
Limit value of flame loss during operation
Modification 0 2 1 0 SO OEM
240.01
Repetitions meter
Limit value of No flame at the end of the safety
time
Modification 0 1 1 1 SO OEM
241.00
Valves Seal Control
0 = OFF
1 = ON
Modification 0 1 1 1 SO OEM
241.01
Valves Seal Control
0 = during pre-purging
1 = during post-purging
Modification 0 1 1 1 SO OEM
241.02
Valves Seal Control
0 = according to P241.01
1 = during pre-purging and post-purging
Modification 0 1 1 0 SO OEM
242 Evacuation of valve seal control test area Modification 0s 2.648 s 0.147 s 2.648 s SO OEM
243
Atmospheric pressure valve seal control time
test
Modification 1.029 s 37.485 s 0.147 s 10.290 s SO OEM
244 Filling the valve seal control test area Modification 0s 2.648 s 0.147 s 2.648 s SO OEM
245 Gas pressure valve seal control time test Modification 1.029 s 37.485 s 0.147 s 10.290 s SO OEM
257 Post-ignition time -0,3 seconds Modification 0s 13.23 s 0.147 s 2.205 s SO OEM
400 Ratio control (operation)
403.00 Fan speed: Ignition load speed (P0) Modification 800 rpm 900 rpm 10 rpm 3000 rpm SO SO
403.01 Fan speed: Low flame speed (P1) Modification 800 rpm 900 rpm 10 rpm 1200 rpm SO SO
403.02 Fan speed: High flame speed (P2) Modification 800 rpm 900 rpm 10 rpm 5700 rpm SO SO
500 Ratio control
503.00 Speed without PWM fan flame: Standby speed Modification 0 rpm 9000 rpm 10 rpm 0 rpm SO SO
