List of parameters PME71.901...
503.01
Speed without PWM fan flame: Speed of impu-
rity purge
Modification 800 rpm 9000 rpm 10 rpm 5700 rpm SO SO
516.00 Limit of ignition load speed (P0): Minimum limit Modification 800 rpm 9000 rpm 10 rpm 800 rpm SO OEM
516.01 Limit of ignition load speed (P0):Maximum limit Modification 800 rpm 9000 rpm 10 rpm 9000 rpm SO OEM
517.00
Limit of low flame speed (P1): Minimum limit
Modification
Modification 800 rpm 9000 rpm 10 rpm 800 rpm SO OEM
517.01 Limit of low flame speed P1: Maximum limit Modification 800 rpm 9000 rpm 10 rpm 9000 rpm SO OEM
518.00 Limit of high flame speed P2: Minimum limit Modification 800 rpm 9000 rpm 10 rpm 800 rpm SO OEM
518.01 Limit of high flame speed P2: Maximum limit Modification 800 rpm 9000 rpm 10 rpm 9000 rpm SO OEM
519 Maximum fan speed Modification 3000 rpm 9000 rpm 10 rpm 5830 rpm SO OEM
522 Low flame acceleration ® high flame Modification 2,058 s 74.970 s 0.294 s 14,994 s SO OEM
523 High flame acceleration ® low flame Modification 2,058 s 74.970 s 0.294 s 14,994 s SO OEM
558
Mode: Information UDS status
0 = PC tool mode
1 = PWM mode
2 = actuator mode
3 = internally
4 = internally
5 = internally
Reading only 0 5 1 0 SO ---
559
PWM mode
0 = open loop control
1 = PID control
2 = safety mode (PWM limits)
Modification 0 2 1 1 SO OEM
560
Mode: Control of pneumatic ratio
0 = OFF
1 = PWM fan
2 = air damper actuator
Reading only 0 2 1 1 SO ---
600
Output setting
644
Number of pulses for rotation
Modification 2 5 1 3 SO OEM
646
Time of speed control adjustment
Modification 1.029 s 2,058 s 0.147 s 2,058 s SO OEM
650.00
Speed tolerance range: Stopping speed
Modification 1% 5% 1% 1% SO OEM
650.01
Speed tolerance range: Rapid stopping speed
Modification 1% 10% 1% 3% SO OEM
654
Analogue input (feedback potentiometer
ASZxx.3x required)
0 = input passage 3 positions
1 = 0...10 V
2 = 0...135 
3 = 0...20 mA
4 = 4...20 mA with lockout at I <4 mA
5 = 4...20 mA
Modification 0 5 1 1 SO SO
658.00
PWM fan values: PWM starting
Modification 1% 100% 1% 25% SO OEM
658.01
PWM fan values: Min. operating interval PWM
Modification 0% 20% 1% 0% SO OEM
658.02
PWM fan values: Max. operating interval. PWM
Modification 80% 100% 1% 100% SO OEM
659.00
Ramp time of fan: Min. low-fire to high-fire
Reading only 0s 74.970 s 0.294 s 2,058 s SO ---
659.01
Ramp time of fan: Max. from high flame to low
flame
Reading only 0s 74.970 s 0.294 s 74.970 s SO ---
659.02
Ramp time of fan: Min. high-fire to low-fire
Reading only 0s 74.970 s 0.294 s
2,058 s
SO ---
659.03
Ramp time of fan: Max. high-fire to low-fire
Reading only 0s 74.970 s 0.294 s 74.970 s SO ---
660
Tolerance time speed deviation
Reading only 0s 37.85 s 0.147 s 4.998 s SO ---
674
Neutral interval (control offset permitted)
Modification 0 rpm 255 rpm 1 rpm 40 rpm SO OEM
675.00
PWM: Min. PWM with pre-purging, SEC
Modification 0% 100% 1% 86% SO OEM
675.01
PWM: Max. PWM with ignition load, SEC
Modification 0% 100% 1% 34% SO OEM
676
Gain factor speed control
Reading only 0 255 1 112 SO ---
677
Integral action time speed control
Reading only 0s 37.485 s 0.147 s 0.441 s SO ---
678
Derivative action time speed control
Reading only 0s 37.485 s 0.147 s 0s SO ---
679.00
Constant time speed control PT1: Min. speed
interval from high flame to low flame
Modification
0s
37.485 s 0.147 s 6,027 s SO OEM
679.01
Constant time speed control PT1: Average
speed interval from high flame to low flame
Modification 0s
37.485 s 0.147 s 6,027 s
SO OEM
679.02
Constant time speed control PT1: Upper speed
interval from high flame to low flame
Modification 0s
37.485 s 0.147 s 6,027 s
SO OEM
679.03
Constant time speed control PT1: Total speed
interval from high flame to low flame
Modification 0s
37.485 s 0.147 s
6,027 s SO OEM
