Riello 20148874 - Resetting of Burner Control; Diagnostics of the Cause of the Fault

20152192
64
GB
Operation, indications, diagnostic
9.3 Resetting of burner control
When a lockout occurs, the burner control can be immediately re-
leased by pressing the “RESET” button (See Fig. 167 on
page 54).
NOTE:
For the meaning of the diagnostic codes and errors, see the
chapter “List of error codes with operation using AZL21... Dis-
play” on page 63.
9.3.1 Diagnostics of the cause of the fault
After the lockout, the faults indicator lamp stays on fixed. Under
these conditions, it is possible to activate the visual diagnostic of
the cause of the fault based on the table of colour codes by keep-
ing the reset button pressed for more than 3 seconds (info but-
ton).
Press the reset button again (info button) for at least 3 seconds
to activate the diagnostics interface.
If the diagnostic interface is started accidentally, a condition sig-
nalled by the blinking red indicator light, it can be deactivated by
pressing the reset button again (info button) for > 3 seconds.
The switching moment is indicated by a pulse of yellow light.
Tab. Y
During the diagnosis of the cause of the fault, the outputs of the
controls are disabled
– The burner stays off
– Indication of external fault (alarm) on the clamp X2-03, foot 3
on fixed
At the outlet of the diagnostic of the cause of the fault the burner
is switched on again by resetting the burner control.
Press the reset button (info button) for about 1 second (<
3 seconds).
Error code table
Red blink code fault indica-
tor light
Possible cause
2 blinks No flame at the end of the safety time
– Fuel valves dirty or defective
– Flame detector dirty or defective
– Burner not adjusted correctly, no fuel
– Ignition device defective
4 blinks – Extraneous light at burner start-up
7 blinks Too many flame losses during operation (limitation of repetitions)
– Fuel valves dirty or defective
– Flame detector dirty or defective
– Burner adjustment incorrect
8 blinks Free
9 blinks Free
10 blinks Wiring error or internal error, outlet contacts, other faults
12 blinks Valve test
– Fuel valve 1 leak
13 blinks Valve test
– Fuel valve 2 leak
14 blinks POC error valve closure control
15 blinks Error code
15 (e.g. according to the type of program module)
error code 20: Min gas pressure switch fault
error code 22: Safety loop error
