Riello GITRE Series - Location of Sensors

11
GENERAL INFORMATION
1.8 Location of sensors
GITRÈ
TS
Tm
TR
1
TS Safety thermostat sensor
Tm Minimum temperature thermostat
sensor
TR Boiler thermostat sensor
1 Boiler temperature gauge
GITRÈ B/100
2
TB
TL1
TL2
Tm
TR
TS
1
TR Boiler thermostat sensor
TS Safety thermostat sensor
TB Storage cylinder thermostat sensor
TL1 Maximum temperature thermostat
sensor
TL2 Heat dissipation thermostat sensor
Tm Minimum temperature thermostat
sensor
1 Boiler temperature gauge
2 DHW thermostat
