Rigaku Progeny - Page 43

Operating Progeny Analyzers 36
1006232_RevD
Categories/Properties
Control
Possible Values
Description
Pass (or Match)
Threshold
Soft Key
 0.80
(default)
 Range:
 0.99 (max)
 0.60 (min)
Opens a settings screen to select the correlation
percentage for matching spectral results. The
property has:
 Decimal format
 Increments of 0.01
Note:
In a Verify type application, this is Pass
Threshold and in an Identify type application,
this is Match Threshold. In either case, it should
be greater than, or equal to, the Search Result
Threshold of the application Apply these settings
in the Application mode
Wavelength Start
Soft Key
 200 cm
-1
(default)
 Range:
 200 cm
-1
(min)
 2,500 cm
-1
(max)
Opens a settings screen through which you can
scroll to select the value.
 Settings available at increments of 50 cm
-
1
.
Note:
Wavelength Start and Wavelength End are only
enabled when Search Algorithm type is set to
HQI.
Wavelength End
Soft Key
 2,500 cm
-1
(default)
 Range:
 2,500 cm
-1
(max)
 200 cm
-1
(min)
Opens a settings screen through which you can
scroll to select the value.
 Settings available at Increments of 50 cm
-
1
.
Search Results
Maximum Number of
Search Results
Soft Key
 Range:
 None
(disabled)
 5 (max)
Opens a setting screen through which you can
scroll to select the value.
 When set to None, or disabled, no library
matches are displayed. Consequently, use
this setting for Verification applications
only.
Settings are available at increments of 1.
Enable Search Result
Threshold
Soft Key

(On
default)

(Off)
When Enable Search Results Threshold is ON the
Search Result Threshold number is used to filter
search results that do not meet the minimum
search threshold value (see next row)
Search Threshold
Soft Key
 0.85
(default)
 Range:
 0.99 (max)
 0.50 (min)
Opens a settings screen to select the library
correlation match value. The lower the value, the
more search results will be displayed. The property
has:
 Decimal format
