8.7.8 Runt Trigger

The runt trigger sets the oscilloscope to trigger pulses that cross one trigger level but

not another, as shown in the figure below.

Lower Limit of the

Trigger Level

Upper Limit of the

Trigger Level

Negative Runt Pulse

Positive Runt Pulse

Figure 8.15 Runt Trigger

Trigger Type

Click or tap the drop-down button of

Type to select "Runt".

Figure 8.16 Runt Trigger Setting Menu

After a trigger type is selected, the current trigger setting information (including the

trigger type, source, and level) is displayed in the trigger information label at the top

of the screen, as shown in the figure below. The information will change based on the

trigger settings.
