RIGOL
2-52 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
3．The stop manner
To set the manner of stop DataLog.
Press Æ Log Æ Stop, enter the interface shows below.
Figure 2-62
The stop condition menu interface
Table 2-38 The stop condition menu explanation
Function
Menu
setting Explanation
Timer
To set the time of DataLog, stop the sample
when the time is over
REC#
To set the sample points of DataLog, stop the
sample when reach the set number
Infinity To set the DataLog don`t stop sampling
Save all the changes, back to a higher level
menu.
