Rigol DP800 Series User Manual

RIGOL Chapter 5 Specifications
5-2 DP800 User’s Guide
Current 0.05%+2mA 0.05% + 2mA 0.05% + 2mA
Voltage Programming Control Speed (1% within the total variation range)
Rise
Full Load <50ms <50ms <11ms
No Load <25ms <25ms <10ms
Fall
Full Load
<30ms
<30ms
<13ms
No Load <400ms <400ms <200ms
OVP/OCP
Accuracy ±(Output
Percentage+Offset)
0.5%+0.5V/0.5%+0.5A
Activation Time
1.5ms (OVP≥ 3V)
<10ms (OVP<3V and OCP)
Mechanical
Dimensions
239mm(W) x 157mm(H) x 418mm(D)
Weight 9.0kg
Power
AC Input
(50Hz-60Hz)
100Vac+10%, 115Vac+10%, 230Vac+10% (maximum 250VAC)
I/O
USB Device 1
USB Host
1
LAN Option
RS232 Option
Digital IO
Option
Environment
Working Temperature
Full Rated Value Output: 0℃ to 40℃
Under Relatively Higher Temperature: the linearity of the output
current reduces to 50% at the highest temperature 55℃
Cooling Method Fan Cooling
Note:
[1] The accuracy parameters are acquired via calibration under 25℃ after 1-hour warm-up.
[2] The maximum time required for the output to change accordingly after receiving the APPLy
and SOURce commands.
[3] The variation of the output within 8 hours after 30-minute warm-up when the load circuit and
environment temperature are constant.
