RIGOL
1-4 © Copyright RIGOL Technologies, Inc. 2007.
User’s Guide for DS1000 Series
Figure 1-2
Front Panel Controls
Character definitions in this User’s Guide:
Throughout this book, character figures of buttons and knobs are the same to those
on front-panel.
A box around the name of the key denotes MENU function buttons on front-panel,
such as Measure.
( ) denotes the multi-function knob .
denotes the two POSITION knobs.
denotes the two SCALE knobs.
denotes the LEVEL knob.
The name with a drop shadow denotes the menu operating key, such as WAVEFORM
soft key in STORAGE menu.
