User’s Guide for DS1000 Series
Chapter 4 : Prompt messages & troubleshooting
Prompting Message
Setting at limit: Prompts that the setting is at limit, can not be adjusted any
further.
Trigger level at limit: Prompts that the trigger level is at limit while turning the
knob.
Trigger position at limit: Prompts that the trigger position is at the start or the
end point of the memory space while turning the horizontal
knob to
adjust the trigger offset.
Volts/Div at limit: Prompts that the Volts/Div is at the limit of the full range while
turning the vertical
knob.
Vertical position at limit: Prompts that the vertical position of waveform is at full
range while turning the vertical
knob.
No active cursor: Prompts that you haven’t set the cursor source while using the
Track cursor measurements.
Delayed scale at limit: Prompts that it is at the full range of horizontal resolution
under the Delayed Scan mode while turning the horizontal knob.
Delayed position at limit: Prompts that the horizontal position of the zoom
window is at limit under the Delayed Scan mode while turning the horizontal
knob.
Function not available: Prompts that this function is not available under current
setting or the current setting is fixed without any adjustment.
Sampling at limit: Prompts that the sampling rate is at limit under the X-Y mode.
Real Time Div at limit: Prompts that the time base is up to the highest horizontal
resolution under the Real-Time sampling mode.
Time/div at limit: Prompts that the horizontal scale is up to the highest horizontal
resolution under the Equivalent-sampling mode.
