© Copyright RIGOL Technologies, Inc. 2007. 6-1
User’s Guide for DS1000 Series
Chapter 6 : Appendix
Appendix A: Specifications
All specifications apply to the DS1000 Series Oscilloscopes and a probe with the
Attenuation switch set to 10X unless noted otherwise. To meet these specifications,
two conditions must first be met:
1 The instrument must have been operating continuously for thirty minutes within
the specified operating temperature.
2 You must perform the Self Cal operation, accessible through the Utility menu, if
the operating temperature changes by more than 5 °C.
All specifications are guaranteed unless noted “typical”.
Specifications
Acquisition
Sampling Modes Real-Time Equivalent
Sampling Rate 400Sa/s
200MSa/s
**
25GS/s
Averages N time acquisitions, all channels simultaneously, N is
selectable from 2, 4, 8, 16, 32, 64, 128 and 256
Inputs
Input Coupling DC, AC, GND
Input Impedance 1MΩ±2%, in parallel with 15pF±3pF
Probe Attenuation Factors 1X, 10X, 100X, 1000X
400V (DC＋AC Peak, 1MΩ input impedance)
Maximum Input Voltage
40V (DC+AC Peak)
**
Time delay between channel
(typical)
500ps
