RIGOL
© Copyright RIGOL Technologies, Inc. 2007.
User’s Guide for DS1000 Series
6-2
Horizontal
Sample Rate Range 1Sa/s-400MSa/s (Real-Time), 25GSa/s (Equivalent)
Waveform interpolation Sin(x)/x
1M samples for single channel, 512K samples for each
channel
Record Length
512K samples
**
Scan speed Range
(Sec/div)
5ns/div-50s/div, DS1102XX, DS1062XX
10ns/div-50s/div, DS1042XX
20ns/div-50s/div, DS1022XX
1-2-5 Sequence
Sample Rate and
Delay Time Accuracy
±100ppm (over any 1ms time interval)
Delta Time
Measurement Accuracy
(Full Bandwidth)
Single-shot: ±(1 sample interval + 100ppm × reading
+ 0.6 ns)
>16 averages: ±(1sample interval + 100ppm × reading
+ 0.4 ns)
