RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 6-3
User’s Guide for DS1000 Series
Vertical
A/D converter 8-bit resolution, each channel samples simultaneously*
Volts/div Range 2mV/div-5V/div at input BNC
Offset Range ±40V(200mV-5V), ±2V(2mV-100mV)
Analog Bandwidth 100MHz(DS1102CD, DS1102C, DS1102MD, DS1102M)
60MHz(DS1062CD, DS1062C, DS1062MD, DS1062M)
40MHz(DS1042CD, DS1042C, DS1042MD, DS1042M)
25MHz(DS1022CD, DS1022C, DS1022MD, DS1022M)
Single-shot
Bandwidth
80MHz(DS1102CD, DS1102C, DS1102MD, DS1102M)
60MHz(DS1062CD, DS1062C, DS1062MD, DS1062M)
40MHz(DS1042CD, DS1042C, DS1042MD, DS1042M)
25MHz(DS1022CD, DS1022C, DS1022MD, DS1022M)
Selectable Analog
Bandwidth Limit
(typical)
20MHz
Lower Frequency
Limit (AC –3dB)
≤5Hz (at input BNC)
Rise Time at BNC,
typical
<3.5ns, <5.8ns, <8.7ns, <14ns,
On (100M) (60M) (40M) (25M) respectively
DC Gain Accuracy 2mV/div-5mV/div:
±4% (Sample or Average acquisition mode)
10mV/div-5V/div:
±3% (Sample or Average acquisition mode)
DC Measurement
Accuracy, Average
Acquisition Mode
Average of ≥16 Waveforms with vertical position at zero:
±(4%×reading+0.1div+1mV) at 2mV/div or 5mV/div
±(3%×reading+0.1div+1mV) at settings 10mV/div-5V/div
Average of ≥16 Waveforms with vertical position not at zero:
±[3%×(reading+vertical position)+(1% of vertical position)
+ 0.2div]
Add 2mV for settings from 2mV/div to 200 mV/div
Add 50mV for settings from 200mV/div to 5V/div
Delta Volts
Measurement
Accuracy (Average
Acquisition Mode)
Delta Volts between any two averages of 16
waveforms acquired under same setup and ambient
conditions: ±(3%×reading + 0.05 div)
