RIGOL
3-12 © Copyright RIGOL Technologies, Inc. 2007.
User’s Guide for DS1000 Series
Example 8: FFT Cursor measurement
FFT measurements include: amplitude measurement (Vrms or dBVrms) and
Frequency measurement (Hz).
Do these steps as follow:
1. Press Cursor→Manual
2. Press Type to select X or Y
3. Press Source to select FFT
4. Turn (
) knob to move the cursor to an interesting point.
Figure 3-9
Figure 3-10
